RCR-Force 12 Supply
Original price was: $1,078.00.$323.40Current price is: $323.40.
In Stock
Description
Description
The RCR FORCE-12 includes twelve tactile switches, in a three-row configuration, with the same style of the previous Switch-Pros systems. The twelve circuit, 170 amp power module will control up to seventeen outputs, using a combination of direct and trigger inputs. Five of the circuits can handle inductive loads, and one circuit is a low side driver.
The RCR-FORCE-12 Kit includes everything required for installation, plus the all-new RCR-Touch snap on bezel, which will help the driver select switches with precision even while traveling rough terrain or wearing gloves.
Specifications
- RCR-Touch™ cover, snaps on for ease of specific switch selection while wearing gloves or riding rough terrain
-
- Switch Panel enclosure measures
4” L x 3” W x .375” H
-
- Splash proof with Polycarbonate overlay faceplate
-
- Pre-machined for factory- look installation
-
- RGB backlighting
-
- Orange LED switch indicators
-
- 6 Programmable LED Status indicators
-
POWER MODULE SPECS:
- 17 Outputs: 4 rated @ 35A, 1 rated @ 30A, 11 rated @15A, 1 Low Side rated @ 2A
-
- 150A maximum rating
-
- 7”L x 3.5”W x .5”H (excluding connectors)
-
- Waterproof and Solid State
-
- Underhood rated 125° to -40°C
-
- LED Ignition Input Status Indicator
-
What s Included
- Switch Pros RCR-Force-12 Panel
-
- Switch Pros RCR-Force-12 Power Module
-
- RCR-TOUCH™ switch cover
-
- 11’ of Communication Cable between Switch Panel and Power Module
-
- Power Cable with 150A inline Circuit protection
-
- 100 User Selectable Legends included (Horizontal orientation)
-
- Installation brackets and hardware
-
- Color Coded Output wires
-
- Wire harness with waterproof, sealed automotive grade connectors
-
Features
- 12 user-programmable switches
-
- RCR-TOUCH™ switch cover
-
- Waterproof, solid state power module
-
- 150amp capacity with 17 outputs
- 4 rated @ 35A and 1 rated @ 30A
(High In-Rush circuits)
-
- 11 rated @ 15A, which can be combined for larger loads
-
- 1 Low Side driver switch, rated @ 2A
-
-
- Built-in Bluetooth module
-
- Program and operate accessories with phone or tablet
-
- System can be used to start vehicle
-
- No bulky relay box
-
- RGB Backlighting with unlimited color options
-
- Three External Trigger inputs can each activate up to four outputs (Active Hi or Active Low)
-
- Sleep Mode for minimal power consumption
-
- Color coded output wires
-
- Daisy Chain up to 3 Switch Panels to One Power Module
-
- Free app for iOs and Android platforms
-
- Splash proof switch panel with Polycarbonate overlay faceplate
-
- LED Input Status Indicators for easy troubleshooting
-
- Battery Voltage Readout on App screen
-
SWITCHES CAN BE PROGRAMMED FOR:
- On Off or Momentary
-
- Ignition or Battery Input
-
- Flash or Strobe, with User-Selectable Strobe patterns and One Touch activation
-
- Memory Function
-
- Master Mode, with ability to turn multiple outputs On AND Off with one touch
-
- Automatic Power-Up upon vehicle start up
-
- Two External trigger inputs can each activate up to four outputs (Active Hi or Active Low)
-
- Lighting outputs can dim from 100% to 10%, with ability to dim during Flash or Strobe patterns
-
- Sleep Mode for minimal power consumption
-
- Color Coded Output wires
-
- 100 User-selectable switch legends
-
- LED Input Status Indicators for easy troubleshooting
-
- Time Delay Off function available for all circuits
-
- Splash proof switch panel with Polycarbonate overlay faceplate
-
- Program and control the system from switch panel pad or smart phone
-
- Bluetooth interface with FREE Apple or Android App
-
- Battery Voltage Readout on App screen
-
- No Fuses or Bulky Relay box
-
- Built-In Bluetooth Module
-
